Ausstattungsliste: Wadia a102
Technical specification | |
Power Output | 50 watts into 8 ohm loads |
80 watts into 4 ohm loads | |
Output Load Impedance | 8 ohms or 4 ohms |
Rated Power Band | 20Hz to 20kHz |
Total Harmonic Distortion | 0.2% maximum harmonic distortion at any level from 250 milliwatts to one-half of rated power output, 20Hz to 20kHz |
0.5% maximum harmonic distortion at any level from one-half to full rated power output, 20Hz to 20kHz | |
Dynamic Headroom | 1dB 8 ohm load |
1.3dB 4 ohm load | |
Frequency response | +0, -0.5dB from 20Hz to 20kHz |
+0, -3.0dB from 10Hz to 50kHz | |
A-weighted Signal to Noise Ratio | 96dB (113dB below rated output) Balanced |
93dB (110dB below rated output) Unbalanced | |
Intermodulation Distortion | 0.1% maximum if instantaneous peak power output does not exceed the rated output for any combination of frequencies from 20Hz to 20kHz |
Wide Band Damping Factor | Greater than 200, 8 ohm load |
Greater than 100, 4 ohm load | |
Input Impedance | 15K ohms Balanced and Unbalanced |
Voltage Gain | 29dB |
Trigger Input | 5-15VDC, <1mA |
Trigger Output | 12VDC, 50mA maximum, delayed 0.2 seconds |
Overall Dimensions | Width 10 inches (25.4 cm) |
Height 3-5/32 inches (8 cm) including feet | |
Depth 14 inches (35.6 cm) including cables | |
Weight | 8.5 pounds (3.9 kg) |
