Ausstattungsliste: BEYMA CD-1014FE/N
Ausstattung & technische Daten
| Specification | |
| Type | Compression Driver |
| Throat diameter | 36 mm |
| Nominal impedance | 8 Ohm |
| Minimum impedance | 5.2 ohm @ 3.5 kHz |
| Re | 4.3 ohm |
| Power capacity | 70 W AES above 1.2 kHz |
| Program power | 140 W above 1.2 kHz |
| Sensitivity | 110 dB 1 W @ 1 m coupled to horn |
| Frequency range | 700-19000 Hz |
| Recom. crossover frequency | 1.2 kHz or higher (12dB/oct min slope) |
| Voice coil diameter | 44.4 mm |
| Flux density | 1.65 T |
| BL factor | 6.6 N/A |
| Diaphragm material | PM4 |
| Magnet | Ferrite |
| External diameter | 120 mm |
| Depth | 66 mm |
| Mounting | Four M5 threaded holes. 90º apart on 101.6 mm (4 in) diameter circle. |
| Net weight | 2 kg |
