Ausstattungsliste: Karan Acoustics Master Collection LINEb
Specification | |
Type | Preamplifier |
Line inputs | 4 balanced (XLR) and 2 unbalaced (RCA) |
Line outputs | 2 balanced (XLR) |
Input impedance | 30kOhm (balanced/unbalanced) |
Output impedance | 90Ohm |
Output level | 1.55V/RMS (nominal) |
18.0V/RMS (maximum/balanced/600Ohm load) | |
Max. input level: (before saturation) | 5.4V/RMS (balanced/unbalanced/Gain set to 6dB) |
3.6V/RMS (balanced/unbalanced/Gain set to 9dB) | |
Gain | +6dB or +9dB (adjustable) |
Frequency response | 20Hz to 20kHz, +/-0dB; (1.5Hz to 3Mhz, -3dB) |
Distortion | THD: 0.003% (Full output, 20Hz to 20kHz) |
IMD: 0.003% (Full output) | |
Speed | Rise and Settling time <450ns |
Slew rate: 1.500V/us (Amplification stages) | |
Signal to noise ratio | >120dB (unweighted) |
AC voltage | 115V or 230V (nominal line voltage) |
AC voltage range | +/- 10% (from nominal line voltage) |
Power Consumption | 60W (maximum) |
Net dimensions | 504 x 126 x 390mm (whd) |
Net weight | 17.4kg |
