Ausstattungsliste: Focusrite Red 4Pre
Ausstattung & technische Daten
| Specification | |
| Type | 58x64 all-in-one interface, 32x32 Dante I/O |
| Microphone Inputs | |
| Connector Type | DB25 Female connector balanced |
| Phantom Power | 48V Phantom Power, Switchable per mic input |
| Frequency Response | 20 Hz - 35 kHz /-0.2 dB |
| Signal to Noise Ratio | 118 dB (A-weighted) |
| Dynamic Range | 118 dB (A-weighted) |
| THD N | 0.0009 |
| Noise EIN | –129 dBu (A-Weighted) |
| Maximum Input level | 19 dBu |
| Gain Range | 0-63dB (1dB increments from 8dB) |
| Common mode rejection ratio | >70dB at 997 Hz Min Gain |
| Input impedance with AIR mode OFF | 6kO |
| Input impedance with AIR mode ON | 2kO |
| Line Inputs 1-4 | |
| Signal to Noise Ratio | 118 dB (A-weighted) |
| Dynamic Range | 118 dB (A-weighted) |
| THD N | 0.0009 |
| Frequency Response | 20 Hz - 35 kHz /-0.2 dB |
| Connector Type | DB25 Female connector balanced |
| Maximum input level | 27dBu |
| Gain Range | 0-63dB (1dB increments from 8dB) |
| Common Mode Rejection Ratio | >70dB at 997 Hz Min Gain |
| Input impedance with AIR mode OFF | 10kO |
| Input impedance with AIR mode ON | 10kO |
| Line Inputs 5-8 | |
| Connector Type | DB25 Female connector balanced |
| Frequency Response | 20 Hz - 35 kHz /-0.2 dB |
| Signal to Noise Ratio | 118 dB (A-weighted) |
| Dynamic Range | 118 dB (A-weighted) |
| THD N | 0.0007 |
| Maximum input level | 26dBu |
| Common Mode Rejection Ratio | >70dB at 997 Hz Min Gain |
| Input impedance with AIR mode OFF | 20kO |
| Input impedance with AIR mode ON | 20kO |
| Instrument Inputs | |
| Connector Type | 1/4" Female TS Unbalanced |
| Frequency Response | 20 Hz - 35 kHz /-0.2 dB |
| Signal to Noise Ratio | 117dB (A-Weighted) |
| Dynamic Range | 117dB (A-Weighted) I |
| THD N | 0.0015 |
| Maximum input level | 15dBu |
| Gain Range | 0-63dB (1dB increments from 8dB) |
| Input impedance with AIR mode OFF | Nominal input impedance = 2M3 |
| Input impedance with AIR mode ON | Nominal input impedance = 2M3 |
