Ausstattungsliste: Zoom ARQ AR-96
Ausstattung & technische Daten
| Specification | |
| Type | Aero RhythmTrak |
| CONTROLLER: PADS | |
| Number of pads | 96 |
| Velocity sensitive | Yes |
| Pressure sensitive | Yes |
| Sensitivity curves | 4 types |
| Velocity (send) | Yes |
| Aftertouch (send) | Yes |
| Number of LEDs | 160 |
| LED color | Multi |
| Accelerometer | Yes |
| Number of parameter knobs | 3 |
| Number of control keys | Base Station: 18 |
| Ring Controller: 11 | |
| INTERFACE | |
| USB MIDI | Yes |
| Bluetooth LE | Connect to Mac/iOS via MIDI over Bluetooth LE |
| LINE INPUTS | |
| Type | 1/4" Phone |
| Number of inputs | 2 |
| Function | Line |
| Impedance | 50 kΩ |
| Gain | +10～-65 dB |
| Dynamic range | 92 dB typ (IHF-A) |
| LINE OUTPUTS | |
| Type | 1/4" TRS Phone |
| Number of outputs | 2 |
| Impedance | 200 Ω |
| Dynamic range | 106 dB typ (IHF-A) |
| PHONES | |
| Type | 1/4" Stereo Phone（20mW x2 [32 Ω]） |
| Impedance | 10 Ω |
| Dynamic range | 102 dB typ (IHF-A) |
| SOUND SYSTEM | |
| Internal sound engine | Yes |
| Sampling frequency | 44.1 kHz |
| Bit rate | 24-bit |
| Maximum polyphony | 16 |
| Number of instruments | 33 |
| Number of oscillator types | 538 (468 PCM sounds + 70 synth sounds) |
| Number of patterns | 384 (176 preset) |
| Number of filter types | 7 |
| Number of Insert FX types | 11 |
| Number of Delay types | 3 |
| Number of Reverb types | 3 |
| Number of Master FX types | 14 |
| Number of Modulation types | 8 |
| Number of Modulations | 2 |
| Number of Envelope Generators | 2 |
| SEQUENCER | |
| Number of Steps s | 32 |
| Motion Sequences | 256 motions |
| Song mode | Yes |
| Tempo | 40.0～250.0 bpm |
| LOOPER: AUDIO CAPTURE | |
| Sampling frequency | 44.1 kHz |
| Bit rate | 16-bit |
| MEDIA | |
| Media type | SD, SDHC, SDXC |
| Internal memory | 32 MB |
| POWER SOURCE: CONTROLLER | |
| Type | Li-ion Polymer |
| DC 4.2V maximum voltage | |
| DC 3.7V nominal voltage | |
| 450mAh capacity | |
| Battery life | About 4.5 hours (differs according to use conditions) |
| Recharging times | 2.5 hours |
| POWER SOURCE: BASE STATION | |
| External Power | AC adapter (AD-14) |
| Rated Output | DC5V / 1A (center positive) |
| Power Consumption | Max: 1.25W (No charging) |
| Max : 4.5W (Charging) | |
| OS SUPPORT: BLUETOOTH LE | |
| Windows | No |
| Mac OS | 10.10.4 or later |
| iOS | 8.0 or later |
| OS SUPPORT: USB MIDI | |
| Windows: | Windows 7 SP1 or later |
| Windows 8 (including 8.1) | |
| Windows 10 | |
| Mac OS | 10.8 or later |
| PHYSICAL MEASUREMENTS: BASE STATION | |
| Dimensions | 260 mm (W) x 64 mm (H) x 260 mm (D) |
| Weight | 990g |
| Display | 2.0 inch (320 x 240) full color TFT |
| PHYSICAL MEASUREMENTS: CONTROLLER | |
| Dimensions | 280.5mm (W) x 33.5mm (H) x 280.5mm (D) |
| Weight | 540 g |
