Kategorie: Verstärker Vorverstärker
Ausstattungsliste: Constellation Audio Altair II
Ausstattung & technische Daten
| Specification | |
| Inputs | 4 XLR stereo, 4 RCA stereo |
| Outputs | 2 XLR stereo, 2 RCA stereo |
| Output noise | <20 uV dB, 20 Hz - 20 kHz |
| THD+N | <0.001%, 20 Hz - 20 kHz @ 2V out, RI >10 K |
| <0.1%, 20 Hz - 20 kHz @ 10V out, RI >10 K | |
| Frequency response | 10 Hz to 200 kHz, +/- 0.5 dB |
| Input impedance (balanced) | 200 K |
| Input impedance (single-ended) | 100 K |
| Output impedance | < 50 ohm |
| Volume control resolution | 0.1, 0.5, or 1 dB; user-selectable |
| Recording outputs | 1 XLR stereo, 1 RCA stereo |
| Weight | 38.2 kg, line stage |
| 11.4 kg, power supply | |
| Dimensions (W x H x D) | 44.5 x 14 x 37.6 cm (whd), line stage |
| 44.5 x 7.2 x 36.8 cm (whd), power supply | |
