Kategorie: AV-Endstufen
Ausstattungsliste: Krell CHORUS 7200
Ausstattung & technische Daten
| Specifications | |
| Frequency response | 20 Hz to 20 kHz +0, –0.08 dB |
| <0.5 Hz to 100 kHz +0, –3 dB | |
| Signal-to-noise ratio | >95 dB, wideband, unweighted, referred to full power output |
| >115 dB, “A”-weighted | |
| Gain | 26.2 dB |
| Total harmonic distortion | <0.04% at 1 kHz, at 200 W, 8 Ω |
| <0.15% at 20 kHz, at 200 W, 8 Ω | |
| Input Impedance | Single-ended: 100 kΩ |
| Balanced: 200 kΩ | |
| Input sensitivity | Single-ended or balanced: 1.96 V RMS |
| Output power | 200 W RMS at 8 Ω |
| 360 W RMS at 4 Ω | |
| Output voltage | 113 V peak-to-peak |
| 40 V RMS | |
| Output current | 13.4 A peak |
| Slew rate | 40 V/μs |
| Output impedance | <0.038 W, 20 Hz to 20 kHz |
| Damping factor | >210, 20 Hz to 20 kHz, referred to 8W |
| Power consumption | Standby: 1 W |
| Idle: 255 W | |
| Maximum: 2800 W | |
| Heat output | Standby: 3.4 BTU/hr. |
| Idle: 873 BTU/hr. | |
| Maximum: 9590 BTU/hr. | |
| Inputs | 7 single-ended via RCA connector |
| 7 balanced via XLR connector | |
| Outputs | 7 pairs binding posts |
| Dimensions | 17.1 in. W x 7.65 in. H x 21.10 in. D |
| 434 mm W x 194 mm H x 536 mm D | |
| Weight | 100 lbs., 45.4 kg (unit only) |
