Ausstattungsliste: MOTU 1248
Ausstattung & technische Daten
| Specification | |
| Type | Studio Interface |
| Sample rates | 44.1, 48, 88.2, 96, 176.4, 192 kHz |
| Mic inputs | 4 x XLR mic inputs |
| Preamp gain: 0 to +63 dB (digitally controlled) | |
| Analog inputs | 2 x 1/4" hi-Z guitar inputs (front panel) |
| 8 x 1/4" TRS line inputs (balanced/unbalanced) | |
| Max level: +24 dBu (digitally adjustable +2 to +24) | |
| Analog outputs | 12 x 1/4" TRS line out (balanced, DC coupled) |
| Max level: +20 dBu (digitally adjustable -4 to +20) | |
| 2 x 1/4" TRS stereo headphone | |
| Digital I/O | 2 banks (16 ch) of ADAT optical at 1x sample rates |
| 1 bank (8 ch) of SMUX optical at 2x sample rates | |
| Stereo RCA S/PDIF up to 96 kHz (with SRC on input) | |
| Stereo TOSLink (optical S/PDIF) on Bank A (optional) | |
| Total I/O | 32 inputs and 34 outputs (66 total) at 1x sample rates |
| 24 inputs and 26 outputs (50 total) at 2x sample rates | |
| 14 inputs and 16 outputs (30 total) at 4x sample rates | |
| Computer I/O | 1 x Thunderbolt (compatible with 1 and 2) |
| 1 x USB 2.0 audio class compliant USB 3.0 and iOS compatible | |
| 1 x AVB Ethernet (requires OS X Yosemite) | |
| Computer I/O channels | Thunderbolt (44.1 to 96 kHz): 128 in/out |
| Thunderbolt (176.4 to 192 kHz): 64 in/out | |
| USB 2.0 (44.1 to 48 kHz): 64 in/out | |
| USB 2.0 (88.2 to 96 kHz): 32 in/out | |
| USB 2.0 (176.4 to 192 kHz): 24 in/out | |
| AVB Ethernet: 16 to 128 in/out, depending on host computer speed | |
| Sync I/O | 1 x word clock in |
| 1 x word clock out | |
| Network I/O | 1 x RJ45 AVB/TSN Ethernet (1 Gbps) |
| AVB streams (8 channels per stream) | 16 in / 16 out @ 44.1 or 48 kHz |
| 16 in / 16 out @ 88.2 or 96 kHz | |
| 8 in / 8 out @ 176.4 or 192 kHz | |
| Headphone | 2 x 1/4" TRS stereo phone (assignable) |
| Phantom power | 4 x individual +48V |
| Front panel | 2 x 1/4" TRS headphone output |
| 2 x TRS hi-Z guitar input | |
| 2 x digital rotary encoders • main/monitor volume | |
| 2 x digital rotary encoders • phone volume | |
| 2 x digital rotary encoders • guitar input gain | |
| 4 x digital rotary encoders • mic preamp gain | |
| 8 x switches • (4) Pad and (4) 48V Phantom switch | |
| 324 x 24 pixel LCD for level meters / menu nav | |
| 1 x AC power switch | |
| Power | International 100-240V autoswitching supply 50-60 Hz • 0.5A max |
| Dimensions and weight (width x depth x height, enclosure only) | 48.3 x 17.75 x 4.5 cm |
| 2.08 kg | |
| with rack brackets removed: | |
| 43.8 cm / 2.04 kg | |
