Ausstattungsliste: Nagra MEZZO
GENERAL | |
Data Storage medium | Internal 8GB Flash memory |
Recording Method | Digital (PCM) or Digital compression (MP3) |
Compression type | ISO MPEG III |
Sampling Rate | Up to 96 kHz PCM and MPEG |
Playback formats | WAV, MP2, MP3, WMA |
Frequency response | 20 Hz – 20 kHz ±0.5dB |
Dynamic range adjust | >40dB MIC |
S/N ratio | 90 dB (ASA “A” weighted |
Dynamic range (recorded file) | >94 dB (Line input 3.5V) |
Microphone EIN | >122 dB (ASA “A” weighted) |
THD+N at 1 kHz | >0.02% (20Hz – 22 kHz ASA “A” weighted) |
Mono/Stereo | Switchable |
INPUTS | |
Mic. filter | 100Hz |
Input sensitivity | 620µV to 76 mV for 0 dB recording |
Mic gain | 0 – 40 dB |
Mic. Inputs | Miniature 3.5mm stereo Jack connector |
Internal Microphones | 2 x Cardioid |
Mic powering | 3V electret (switchable ON / OFF) |
A.G.C. | Switchable (On/Off) |
Line Input | Miniature 3.5mm stereo Jack connector |
OUTPUTS | |
Headphone | Miniature 3.5 mm stereo Jack connector |
Power | 2x30mW (16Ω) |
Built-in speaker | 0.1W |
USB | 2 |
POWER SUPPLY | |
Battery pack | 2 x “AA” cells |
Consumption | 170mW |
Autonomy | >40 hours |
PHYSICAL | |
Dimensions | 138 x 41 x 19 mm (5.4 x 1.7 x 0.5″) |
Weight | 71 g without batteries |
Operating temperature | 0 – 70°C |
Working humidity | 20 – 80% |
