Ausstattungsliste: SEEBURG GL 8 a
Ausstattung & technische Daten
| Specification | |
| Speaker Components | 2 x 6,5“ Nd / 8 x 1“ Nd Tweeter |
| Description | Cylindric Wave Radiator |
| Power AES / Peak | LF: 200 W / 600 W |
| HF: 75 W / 225 W | |
| Impedance nominal | LF: 16 Ω |
| HF: 16 Ω | |
| SPL 1 W / Peak @ 1 m | LF: > 93 dB / 121 dB |
| HF: > 94 dB / 118 dB | |
| Usable Range | 80 Hz - 20 kHz (- 6 dB) |
| Tuning Frequency excursion minimum | 90 Hz |
| X-Overpoint acoustical | Depends on preset |
| Coverage horizontal / vertical | 100° x 7° (i-version) |
| 100° x 31° (c-version) | |
| Mechanical Splay Angle | 0° (i-version) |
| 24° (c-version) | |
| Connectors | 2 x Neutrik Speakon NL4MP in/out |
| Coding: 1 +/- HF, 2 +/- LF | |
| Handles | 1 x |
| Rigging / Fittings | 8 x M10 (i-version) |
| 6 x M10 (c-version) | |
| Weight | 8,5 kg |
| Size height x width x depth | 36,2 x 18,9 x 24,5 cm (i-version) |
| 38,0 x 18,9 x 25,8 (24,5) cm (c-version) | |
