Ausstattungsliste: Audiocontrol The Director® Model M6400
Ausstattung & technische Daten
| INPUTS | |
| Inputs | 8 Stereo Local Inputs, 2 Digital S/PDIF Inputs |
| Input Sensitivity | 1 Vrms for full output, level at maximum |
| Input Gain | 27 dB |
| OUTPUTS | |
| Amplifier Channels | 16 |
| Power Output (8Ω) | 65W per channel |
| Power Output (4Ω) | 100W per channel |
| Power Output (8Ω Bridged Mono) | 175W |
| Minimum Speaker Load | 4Ω |
| Preamp Audio Outputs | 8 Stereo Loop Outputs, 2 Digital S/PDIF Outputs |
| PERFORMANCE | |
| Crosstalk | > 80 dB @ 1 kHz |
| Damping Factor | >200 |
| Signal to Noise | >95 dB, A-wtd, ref full output |
| Crosstalk | > 80 dB @ 1 kHz |
| DAC Specifications | 32 – 96 kHz sample rate, 16/24 bit depth |
| CONTROL | |
| Remote Power Trigger | +12 VDC or Dry Contact Closure |
| Network Connection/Protocol | 10BaseT Ethernet TCP/IP |
| Communication Protocol | HTTP or Telnet |
| GENERAL | |
| Power Consumption (Stand By) | <2W |
| Power Consumption (Idle) | 35W |
| Power Consumption (loud listening level) | 220W |
| Power Consumption (maximum) | 1300W |
| BTU/Hour Heat Dissipation (Standby) | 6.8 |
| BTU/Hour Heat Dissipation (Idle) | 121 |
| BTU/Hour Heat Dissipation (loud listening level) | 314 |
| BTU/Hour Heat Dissipation (maximum) | 890 |
| Protection | clipping, short circuit, thermal, ultrasonic, DC offset, stable into reactive or mismatched loads |
| WEIGHTS & DIMENSIONS | |
| Dimensions | 17” W x 15.5” D x 3.5” H (2U) |
| Weight | 16.0lbs (7.26 kg) |
