Ausstattungsliste: Electro-Voice ELX200-15
Ausstattung & technische Daten
| Specification | |
| Type | 15" Passive Loudspeaker |
| Weight Net | 18.7kg (41.23 lbs) |
| Depth | 384mm (15.12") |
| Width | 423mm (16.65") |
| Height | 710mm (27.95") |
| Suspension | (3) M10 suspension points |
| Grille | 18 AWG steel with powdercoat |
| Enclosure Material | Polypropylene Composite |
| Connector Type | Dual NL4 |
| Minimum Impedance | 7.0Ω |
| Crossover Frequency | 1.6 kHz |
| HF Transducer | DH-1C 1-inch titanium compression driver |
| LF Transducer | EVS-15M 381 mm (15 in) |
| Coverage (Nominal -6 dB) V | 60° |
| Coverage (Nominal -6 dB) H | 90° |
| Max. SPL/1m (calc) | 130dB |
| Recommended High-Pass Frequency | 42Hz |
| Frequency Response (-3 dB) | 77 Hz - 16 kHz |
| Speaker Type | Full-Range |
| Available Color | Black or White |
| Nominal Impedance | 8Ω |
| Axial Sensitivity (SPL, 1 W @ 1 m) | 95dB |
| Power Rating | 1200W |
| Woofer Size | 15inch |
| Frequency Range (-10 dB) | 52 Hz - 19 kHz |
| Power Handling (Continuous / Peak) | 300 W/1200W |
