Kategorie: CD-Player
Ausstattungsliste: Luxman D-03X
Ausstattung & technische Daten
| Specification | |
| Supported media | CD、CD-R、MQA-CD |
| Digital input/output | Input ：USB x 1, COAX x 1, OPT x 1／Output：COAX x 1, OPT x 1 |
| Sampling frequency | USB input (PCM)：44.1k, 48k, 88.2k, 96k, 176.4k, 192k, 352.8k, 384 kHz (16, 24, 32bit) |
| USB input (DSD)：2.82M, 5.64MHz (1bit), 11.28MHz (1bit) | |
| USB input (MQA)：44.1k, 48 kHz (24bit) ／(MQA renderer mode)：88.2k, 96 kHz (24bit) | |
| COAX／OPT input：44.1k, 48k, 88.2k, 96k, 176.4k, 192kHz (16, 20, 24bit) | |
| Analog output | Unbalanced x 1, Balanced x 1 |
| Analog output voltage / impedance | 2.4 V／300Ω(Unbalanced), 600Ω(Balanced) |
| Frequency response | CD 5Hz～20kHz(+0, -0.5dB), USB 5Hz～50kHz(+0, -3.0dB) |
| Total Harmonic Distortion ／ S/N ratio (IHF-A) | CD 0.0015%, USB 0.0009%／CD 122dB, USB 123dB |
| Exterior | [Front panel] Power switch, Play/Pause/Stop/Track forward/Track back, Disc eject key, Disc tray, Output phase inverter, digital input switch (digital output on/off), FL display, MQA decode indicator |
| Rear panel] Input terminals, AC inlet | |
| [Remote functions] Disc eject, Disc operation, numeric keys, Display zoom, time display switch, digital input/output switch, Display dimmer, Output phase inverter, Track program order/random/repeat | |
| Dimension | 440 (W) ×133 (H) × 410 (D) mm (Including 2mm front buttons & 8mm rear terminals) |
| Weight | 13.2kg(Unit) |
| Power consumption | 18W, 1W (at standby) |
