Ausstattungsliste: Parasound NewClassic 2250 v.2
Ausstattung & technische Daten
| Specification | |
| All Channels Driven | 275 watts x 2, 8Ω |
| 400 watts x 2, 4Ω | |
| 400 watts x 2, 2Ω (Load switch set to 2-3Ω) | |
| Bridged Mono | 750 watts x 1, 8Ω |
| 750 watts x 1, 4Ω (Load switch set to 2-3Ω) | |
| Current Capacity | 45 amps peak per channel |
| Frequency Response | 20 Hz - 50 kHz, +0/-3 dB, 1 watt |
| Dynamic Headroom | - 1.6 dB |
| Total Harmonic Distortion | 0.20% at full rated output |
| 0.015% at average listening levels | |
| IM Distortion | - 0.05 % |
| Transient IM Distortion | Not measurable |
| S/N Ratio | 114 dB at rated output, IHF A-weighted |
| 106 dB at rated output, unweighted | |
| 93 dB at 2.828 V output, IHF A-weighted | |
| 84 dB at 2.828 V output, unweighted | |
| Input Impedance | - 33 k Ω |
| Input Sensitivity | 1 V in for 28.28 V out, THX standard |
| Inter-Channel Crosstalk | 85 dB @1 kHz, 73 dB @10 kHz, 67 dB @ 20kHz |
| Damping Factor | Over 150 at 20Hz |
| 12V Trigger Turn On | DC 9 – 12V, 15 mA |
| Audio Turn On | Quieter: 1 mV |
| Louder: 6 mV | |
| AC Power Requirement | 110 - 120 V / 220 -240 V, 50 - 60 Hz |
| 0.5 watts standby | |
| 35 watts Idle (no audio) | |
| 1000 watts full output | |
| Dimensions | 17.25" Wide |
| 18.5" Deep, with cables connected | |
| 6" High with feet, 5.25" panel only (3U) (437 x 470 x 153mm, 133mm panel only) | |
| Net Weight | 43 lbs (19.5 kg) |
