Ausstattungsliste: Bryston 6BSST²
Ausstattung & technische Daten
| Features | |
| Balanced XLR and Single ended RCA input | |
| 3 Channels each with fully independent power supplies including separate transformers | |
| 300W into 8 ohms (and up to 500 into 4 ohms) per channel | |
| Switchable gain (23dB or 29dB) | |
| Fully convection cooled means no noisy fans | |
| Machined and anodized aluminum enclosure and dress panel | |
| Less than 500mW standby power consumption | |
| SoftStart microprocessor controlled startup sequence won | |
| DC trigger for automated turn on and turn off | |
| Silver or black faceplate | |
| 17” or 19” faceplate (non-rack mountable). PRO version features 19" Black rack mountable face plate and rear channel trim pots | |
| Specification | |
| Dimensions | Inches: 17 or 19 W x 8 H x 19.25 or 21 (with front handles) D |
| Weight | 103 lbs | 47 kg |
| Frequency Response | <1Hz - 100kHz: -3dB |
| THD+N (20Hz-20kHz @ Rated Power, 8Ω) | <0.005% |
| Power Output (per channel) | 300W @ 8Ω | 500W @ 4Ω |
| Noise | RCA: <-112dB |
| XLR: <-117dB | |
| Input Impedance | Unbalanced 10kΩ |
| Balanced 50kΩ | |
